Unions - CPVC Schedule 80

PART	NOMINAL SIZE	UNION - S × S	UNIT OF MEASURE: MM
		D	d	d1	d2	L1	L2	APPROX. WT.
0408.UNES.0050	1/2"	44.20	13.00	21.54	21.23	22.20	55.00	0.05
0408.UNES.0075	3/4"	55.60	18.20	26.87	26.57	26.00	63.80	0.08
0408.UNES.0100	1"	66.50	24.00	33.65	33.27	28.60	69.50	0.13
0408.UNES.0125	1 1/4"	82.20	30.50	42.42	42.04	33.80	79.90	0.19
0408.UNES.0150	1 1/2"	98.10	38.20	48.56	48.11	34.80	81.50	0.34
0408.UNES.0200	2"	120.00	50.00	60.63	60.17	38.10	98.00	0.58
0408.UNES.0250	2 1/2"	120.00	50.00	73.38	72.85	41.50	98.00	0.60
0408.UNES.0300	3"	184.00	75.00	89.31	88.70	47.60	118.00	1.30
0408.UNES.0400	4"	199.00	100.00	114.76	114.07	57.20	156.00	2.17

PART	NOMINAL SIZE	UNION - T × T	UNIT OF MEASURE: MM
		D	d	d1	d2	L1	L2	APPROX. WT.
0408.UNET.0050	1/2"	44.20	13.00	21.54	21.23	22.20	55.00	0.05
0408.UNET.0075	3/4"	55.60	18.20	26.87	26.57	26.00	63.80	0.08
0408.UNET.0100	1"	66.50	24.00	33.65	33.27	28.60	69.50	0.13
0408.UNET.0125	1 1/4"	82.20	30.50	42.42	42.04	33.80	79.90	0.19
0408.UNET.0150	1 1/2"	98.10	38.20	48.56	48.11	34.80	81.50	0.34
0408.UNET.0200	2"	120.00	50.00	60.63	60.17	38.10	98.00	0.58
0408.UNET.0250	2 1/2"	120.00	50.00	73.38	72.85	41.50	98.00	0.60
0408.UNET.0300	3"	184.00	75.00	89.31	88.70	47.60	118.00	1.30
0408.UNET.0400	4"	199.00	100.00	114.76	114.07	57.20	156.00	2.17
